脉冲激光二极管pLD

905nm脉冲激光二极管pLD

905-Series

905D3J08-Series

905D1S3J0xx-Series

905D1SxxUA-Series

905D3J09-Series

905D1S1.5X

905nm, 3W, 37.5×1μm, iFM(max)=3.5A, 占空比0.1%

905D1S03X

905nm, 6W, 75×1μm, iFM(max)=7A, 占空比0.1%

905D1S03UA

905nm, 6W, 75×1μm, iFM(max)=7A, 占空比0.1%, 高性价比

905D1S06X

905nm, 13W,150×1μm, iFM(max)=15A, 占空比0.1%

905D1S2J03X

905nm, 15W

905D1S09X

905nm, 19W, 230×1μm, iFM(max)=22A, 占空比0.1%

905D1S09UA

905nm, 19W, 230×1μm, iFM(max)=22A, 占空比0.1%, 高性价比

905D2S06X

905nm, 25W, 150×125μm, iFM(max)=15A, 占空比0.1%

905D1S2J06X

905nm, 25W

905D1S3J03X

905nm, 25W, 85×10μm, iFM(max)=11A, 占空比0.1%

905D1S3J03UA

905nm, 25W, 85×10μm, iFM(max)=11A, 占空比0.1%, 高性价比

905D1S12X

905nm, 26W, 300×1μm, iFM(max)=30A, 占空比0.1%

905D1S16X

905nm, 34W, 400×1μm, iFM(max)=40A, 占空比0.1%

905D1S2J09X

905nm, 40W

905D1S3J06X

905nm, 50W, 160×10μm, iFM(max)=22A, 占空比0.1%

905D1S3J06UA

905nm, 50W, 160×10μm, iFM(max)=22A, 占空比0.1%, 高性价比

905D3S09X

905nm, 55W, 230×225μm, iFM(max)=22A, 占空比0.1%

905D3S12X

905nm, 70W, 300×225μm, iFM(max)=30A, 占空比0.1%

905D1S3J08X

905nm, 70W, 200×10μm, iFM(max)=40A, 占空比0.1%

905D1S3J09X

905nm, 70W, 235×10μm, iFM(max)=30A, 占空比0.1%

905D1S3J09UA

905nm, 75W, 235×10μm, iFM(max)=30A, 占空比0.1%, 高性价比

905D4S12X

905nm, 90W, 300×340μm, iFM(max)=30A, 占空比0.1%

905D4S16X

905nm, 130W, 400×340μm, iFM(max)=40A, 占空比0.1%

905D2S3J09X

905nm, 135W, 235×200μm, iFM(max)=40A, 占空比0.1%

905D2S3J08X

905nm, 140W, 200×125μm, iFM(max)=40A, 占空比0.1%

905D3S3J09X

905nm, 200W, 235×400μm, iFM(max)=40A, 占空比0.1%

905D3S3J08X

905nm, 210W, 200×250μm, iFM(max)=40A, 占空比0.1%
